LED pixel light line
|
Company Details:
|
Our Service
1.OEM&ODM.
If you have desiged the drawing for some kinds of lightings, we can do the finish product regards to your drawing. products are in good quality and cheap price; or if you need the product have some functions, We can designed the product with that speciall characteristic to meet your requiryment
2.after-sales service
During your using our product, if there are fault products that due to our qulity,We will provide you the same one freely. If you have any questions on using the product, We will be gald to give you any help.
3.Warranty:3 years
Maybe you will have questions as below
(1) What is LED pixel? What you have?
LED pixel is including wire and light body. it is a dot light. We can use it to make led letter signs,3D Channel letters.
RGB and fullcolor with IC will bring us beautiful viewing. We use RGB control to make it change color, Decoration our
world.
We have 6mm, 9mm, 12mm,20mm,30mm,40mm,50mm led pixels. Red/Green/Blue/Yellow/White/Pink/Purple/RGB/
Fullcolor available. 1903 led pixel, 2812IC,8206,1916ic....
(2) What is an RGB LED pixel
RGB means there is 3 leds in the lamp. Red, Green,Blue chips. There are 2 kinds of rgb pixels.
RGB without IC. It use RGB Control to make it colorchanging. But it only can show 1 color a time. Red color or Green color or blue color.
single color flicking ,or one color change to another color.
RGB with IC like 1903, 2811,2812,1916,2806..., It also named digital led pixels. RGB control control IC to make the light show any color
you want. So 1 string pixels can show many colors at a time.
(2) How RGB LED pixel connect with driver and RGB Controller?
see the information below:
360W12V-GLC-V1 RGB controller is a use of the most advanced PWM (Pulse Width Modulation) digital control technology; switching can be achieved in different colors (jump), brightness adjustment, speed adjustment function, widely used in building lighting, KTV, bars and other night games, mainly for LED products: LED colorful hard / soft light bar, LED perforation lights, LED modules, etc. |
型号/Model | 360W12V-GLC-V1 | ||||||||
输入电源/Input Power | DC5-DC24V | ||||||||
信号输出/Signal output | PWM | ||||||||
输出电流/Output Current | 3*10A | ||||||||
控制方式/control mode | 共阳极/Common anode | ||||||||
驱动LED数量/Driving leds | 模组/Module:七彩9RGB 500PCS | ||||||||
灯条/Strip:30-5050 50M;60-5050 25M | |||||||||
RGB穿孔灯/RGB Piercing Light: 500PCS | |||||||||
包装尺寸/Size | 110*90*25mm | ||||||||
重量/Net Weight | 260g | ||||||||
Maximum Load Power | 5V/150W,12V/360W,24V/720W |
效果/Effect | 备注Remark | 效果/Effect | 备注Remark | ||||||
1 | 静态红/Static red | * | 9 | 七色跳变/Rainbow hopping | # | ||||
2 | 静态绿/Static Green | * | 10 | 三色渐变/Three-color gradient | # | ||||
3 | 静态蓝/Static Blue | * | 11 | 七色渐变/Rainbow Gradient | # | ||||
4 | 红绿色/red Green | * | 12 | 红/绿/蓝频闪/R/G/B while strobe | # | ||||
5 | 红蓝色/red Blue | * | 13 | 七彩跳变+渐变/hopping + gradient | # | ||||
6 | 绿蓝色/Green Blue | * | 14 | 红绿蓝渐亮渐灭/RGB gradually getting off | # | ||||
7 | 红绿蓝/red Green Blue | * | 15 | 红绿蓝流水并闪烁/Flashing red green and blue water | # | ||||
8 | 三色跳变/Three color | # | 16 | 同时按+-从1跑到15/At the same time+ - 1 to 15 | |||||
以上*为亮度可调,#为速度可调/* Adjustable brightness above, # of adjustable speed |
