Product Details:
Payment & Shipping Terms:
|
| Products: | DC12V 5050 SMD Moduli | Power: | 0.72W |
|---|---|---|---|
| Voltage: | DC12V | LED: | 5050 Led |
| Color: | Green | IP Rate: | IP67 |
| Application: | Arcylic Channel Letters | Size: | 75*12*05 Mm |
✅ Support custom color, power and logo printing.
✅ Fast lead time for bulk orders, flexible MOQ.
✅ Professional technical support for sign project solution.
✅ Full certificates CE & RoHS to meet European market requirement.
✅ After-sales service: quick response for quality problems.
| Model No. | MJ-5050-G-outdoor |
| Light sources | 5050 SMD 3 led |
| Chip material | AlGaInP |
| Input voltage | DC 12V |
| Lumen | 42-50LM |
| Power | 0.72w |
| IP rank | IP67 |
| Certification | CE,RoHS |
| Dimension | 75*12mm |
| Lifespan | 50000 hours |
| Color | green |
| Angle Beam | 120dg |
| Operating temperature | —40-60℃ |
| Color temperature | 2700-20000K |
| Optical attenuation | 1000H≥5% |
| Color rendering index | 70Ra |
| Warranty | 2 year |
Feature:
1. Easy installation with 3M adhesive tape on back.
2. DC low voltage power supply, safe for operation.
3. Flexible parallel connection, convenient for custom sign size.
4. Good heat dissipation, reduce failure rate.
5. Multiple color options for different advertising signs.
Installation Tip:
—Silicon glue or 3M double tape directly fixing modules.Pls Cleaning or polishing module surface before the installation.
—Can use screw mounting the modules on the board.
—Single led module can be cut off.
1year warranty, life-long maintenance. Answer will be replied in 24hours.
Technican will solve the problem on site.
Give product upgrade solution to improve plane.
We will give phone call interviews every month during warranty period
Package:
20pcs/string, 5000pcs/curton. Packing picture as below:
Products packaged well should be storaged in dry environment and lower than 60%RH humidity. When it is rainly, pls keep the warehouse dry.
If packed goods are kept over than 1 month, it is suggested to take out to do aging test for 2 hours and then pack up again.
Application:
LED channel letters
Name board
Wine bar wall decoration
building and stage decoration.
Shop advertising
Q5: What’s the lifetime of these LED modules?
A: Up to 50,000 hours under normal working condition.
Q6: Do you accept customized order?
A: Yes, we support custom color, power, PCB size and logo printing.
Q7: What certificates do you have?
A: CE and RoHS certificates available.
Q8: What if some modules do not light up after installation?
A: First check positive and negative wiring. Then check if power supply matches total load. Contact us if quality defect.
